Model | TapShankØD | TapShank□ | TC312(#1) | TC820(#2) | TC1433(#3) |
---|---|---|---|---|---|
ISO529/2283TapM10 | 2.24 | 1.8 | ˙ | 0 | 0 |
ISO529/2283TapM12 | 2.5 | 2 | ˙ | 0 | 0 |
ISO529/2283TapM14 | 3.15 | 2.5 | ˙ | 0 | 0 |
ISO529/2283TapM16 | 3.55 | 2.8 | ˙ | 0 | 0 |
ISO529/2283TapM18,M20 | 4 | 3.15 | ˙ | 0 | 0 |
ISO529/2283TapM22 | 4.5 | 3.55 | ˙ | 0 | 0 |
ISO529/2283TapM24 | 5.6 | 4.5 | ˙ | 0 | 0 |
ISO529/2283TapM27,M30 | 6.3 | 5 | ˙ | ˙ | 0 |
ISO529/2283TapM3 | 7.1 | 5.6 | ˙ | ˙ | 0 |
ISO529/2283TapM3.5 | 8 | 6.3 | ˙ | ˙ | 0 |
ISO529/2283TapM33 | 9 | 7.1 | ˙ | ˙ | 0 |
ISO529/2283TapM36 | 11.2 | 9 | ˙ | ˙ | ˙ |
ISO529/2283TapM4 | 12.5 | 10 | 0 | ˙ | ˙ |
ISO529/2283TapM4.5 | 14 | 11.2 | 0 | ˙ | ˙ |
ISO529/2283TapM5 | 16 | 12.5 | 0 | ˙ | ˙ |
ISO529/2283TapM6 | 18 | 14 | 0 | ˙ | ˙ |
ISO529/2283TapM7 | 20 | 16 | 0 | 0 | ˙ |
ISO529/2283TapM8 | 22.4 | 18 | 0 | 0 | ˙ |
ISO529/2283TapM9 | 25 | 20 | 0 | 0 | ˙ |
ISO52TapM1~2 | 2.5 | 2 | ˙ | 0 | 0 |
ISO52TapM10 | 2.8 | 2.24 | ˙ | 0 | 0 |
ISO52TapM2.2~M2.6 | 3.15 | 2.5 | ˙ | 0 | 0 |
ISO52TapM3 | 3.55 | 2.8 | ˙ | 0 | 0 |
ISO52TapM3.5 | 4 | 3.15 | ˙ | 0 | 0 |
ISO52TapM4 | 4.5 | 3.55 | ˙ | 0 | 0 |
ISO52TapM4.5 | 5 | 4 | ˙ | 0 | 0 |
ISO52TapM5 | 6.3 | 5 | ˙ | ˙ | 0 |
ISO52TapM6 | 7.1 | 5.6 | ˙ | ˙ | 0 |
ISO52TapM7 | 8 | 6.3 | ˙ | ˙ | 0 |
ISO52TapM8 | 9 | 7.1 | ˙ | ˙ | 0 |
ISO52TapM9 | 10 | 8 | ˙ | ˙ | 0 |
